2010-2014 Ford 6.2L Raptor / F-150 Whipple Supercharger System

1 9

2010-2014 Ford 6.2L Raptor / F-150 Whipple Supercharger System

THE BIGGEST, THE BADDEST, MOST EFFICIENT, MOST POWERFUL SUPERCHARGER SYSTEM

NOW FEATURING THE GEN 4 2.9L

Since 1987, Whipple Superchargers™ have been the pioneers and leaders of twin-screw supercharging. With over 31 years of twin-screw supercharging experience, Whipple’s team have now engineered the most powerful intercooled twin-screw SC system available today for your Ford Raptor. With all the latest technology, the all new Whipple system makes more power than any other positive displacement supercharger system on the market giving you tire frying, neck whipping power that will give you a grin from ear to ear. The new Whipple system is 100% complete and is designed for stock engines but has enough capability to work with heavily modified engines.

The all-new system features Whipple’s massive oversized air-to-water intercooler for unmatched cooling capacity, a unique Gen 4 front feed W175ax (a whopping 2.9 liters) integrated Whipple twin-screw supercharger that reaches 99% volumetric efficiency and industry leading power potential. The unique intercooled bypass system offers better acceleration and less than 1hp of consumption during cruising for excellent fuel economy. The system also includes high-flow fuel injectors, aluminum high flow intake manifold and a Whipple Reflash for the factory ECU recalibration. While others claim, Whipple Superchargers simply deliver more power per pound of boost than any other supercharger on the market today.

50 State Legal: EO #D231-63

Whipple's Superior Engineering

Whipple Superchargers quality is second to none. From the beautiful pocketed aluminum pulleys, OEM quick connect fittings, sheeved hoses or blend of casted and billet accents, the Whipple fit and finish allows you to not only have the most power available, you'll also have the best looking SC system available today.

Exclusive Features

Front entry W175ax (2.9 liters) Whipple twin-screw supercharger that significantly outflows competitions 2.3L roots-type systems
Integrated casting to minimize bolt on pieces, adapters, leaks and flow restrictions
Integrated Crusher™shaped inlet for maximum airflow capacity and minimal rotor cavitations
Integrated Crusher™172mm oval inlet outflows smaller 90mm inlets such as other systems
Big Mouth Whipple Crusher™ plastic air inlet for increased velocity and lower inlet temps vs. steel and aluminum tubes
Optional Crusher™ 172mm billet mono-blade throttle body
Integrated design allows for oversized intercooler core compared to other smaller intercooler cores giving Whipple lower air charge temps which allows more boost and timing to be run on pump gas
Massive air-to-water aluminum bar-plate intercooler offers more cooling than any other positive displacement system available
Whipple Superchargers massive oversized intercooled air-bypass system for industry leading reduction of burst knock and incredible fuel economy
Self-contained oversized oil system for dramatically reduced oil temps in even the most demanding conditions
Exclusive 3x5 rotor combo for significant increase in airflow under the curve than less efficient 4x6 rotor combo
Center discharge port for better cylinder to cylinder distribution then other twin-screws with cobbled together billet adapters and forward facing discharge
Discharge down design allows for less pressure loss which gives more power at lower boost levels
Top mount design allows for cooler operation then upside down SC’s that conduct heat from engine and are trapped by runners and covers, causing hotter manifold temps and less power per pound of boost
More boost at the “hit” than any other twin-screw
Flat torque curve for incredible acceleration
Oversized heat exchanger for incredible intercooler water temps
Fits under factory hood with no modifications
No internal modifications required
Completed installation looks factory installed, not some cobbled together kit with multiple billet adapters
Kits come complete with all necessary parts and hardware for installation
Unique oil level sight glass for easy oil level and quality check, no dipstick to bind or misread
Plug and play wiring, no cutting
High flow air filter system, coolant reservoir is maintained
High flow fuel injectors (47lb/hr)
Proven 6-rib belt system with heavy duty spring loaded tensioner and adjustable idler system
Stainless steel jack-shaft with unique plastic cover for increased safety
OEM quick connect fittings for easy installation
Complete and tuner kits available
Available in wrinkle black, polish or any custom color
Easily upgradeable with bigger throttle bodies (172mm or twin 68mm)
Instant boost at the touch of the throttle
3 minute pulley changes
1 year warranty for all parts included

Front Inlet Vs. Rear Inlet

The Whipple front feed system is far superior to rear inlet based SC systems for a very simple reason, less airlfow restrictions. The fact is simple, the front entry systems do not require multiple 90deg bends or one sweeping 180deg bend before the SC inlet, which causes unequal rotor filling and lower volumetric efficiency. The Whipple front entry system requires 1 less bend (1 vs 2) than any rear entry SC resulting in less pumping losses and less “work” required for proper airflow.

Whipple Fuel System

The Whipple SC system comes with Bosch 47 lb/hr fuel injectors that are rated up to 80psi of fuel pressure giving you the capacity for far greater power levels then standard systems.

The Whipple Advantage

The Whipple Advantage is designed into every Whipple SC system. This advantage is broken down into 5 categories during the design and testing phases which truly sets Whipple apart from others:

1. Best power for money.

2. Most complete package.

3. Maximum power.

4. Maximum power expandability.

5. Aesthetic appeal.

What does this mean? You get it all, in one package. Massive power gains with the biggest superchargers, biggest intercoolers, biggest intercooler systems, biggest air-inlet systems while providing robust belt systems and heavy-duty spring tensioners. The intake manifold is designed with high velocity in mind, while increasing plenum volume to lower pressure loss at high power applications.

You then get OEM style fuel and vacuum hoses with nylon sheaving for added protection and appeal, OEM style quick connect fittings with billet aluminum fittings. No ugly brass fittings hanging off the inlet like some others. Wire extensions are injection molded to allow simple plug-and-play installations. Each system also has multiple options for increased performance such as oversized heat-exchangers with dual fans, billet high flow throttle bodies, oversized cold air intake systems just to name a few.

Each kit comes with step-by-step instruction manuals printed in color to help all installers, including the do-it-yourselfer. Kits come with all the fasteners, all color matched for proper aesthetic appeal.

So don’t be fooled by others, there is no comparing to the Whipple supercharger systems, simply the top of the line packages designed and built to exceed all expectations.
